0760554103
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Impact 76055 ROHS3Compliant GENERAL PURPOSE MULTIPLE MATING PARTS AVAILABLE Connector Header, Male Pins -55C~85C 30V 30.0muin 0.76mum
PDF
/
Inventory: 3158
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material NOT SPECIFIED
Mounting Type Through Hole
Technical
Operating Temperature -55°C~85°C
Packaging Tray
Series Impact 76055
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
ECCN Code EAR99
Connector Type Header, Male Pins
Number of Positions 150
Color Black
Number of Rows 15
Voltage - Rated 30V
Additional Feature IMPACT, POLARIZED, STACKABLE
HTS Code 8536.69.40.40
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.053 1.35mm
Total Number of Contacts 150
Number of Positions Loaded All
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code 94V-0
Connector Style Impact, Guide Right
Contact Layout, Typical 50 Differential Pairs
Number of Columns 10
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
