0752374224
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
GbX 75237 ROHS3Compliant Straight Shielded Connector Header, Male Pins UL94V-0 1mOhm 105C 120V
PDF
/
Inventory: 3756
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Length 52.53mm
Technical
Number of Columns 25
Contact Layout, Typical 125 Differential Pairs
Connector Style GbX Guide Right
Max Voltage Rating (AC) 120V
Contact Resistance 1mOhm
Housing Color Grey
Contact Finish Gold
Number of Positions Loaded All
Depth 31mm
Orientation Straight
Pitch 0.073 1.85mm
Voltage - Rated 120V
Number of Rows 10
Color Gray
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 250
Connector Type Header, Male Pins
Termination Press-Fit
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Shielded
Series GbX 75237
Packaging Tray
Physical
Housing Material Polymer
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
