0459854182
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
EXTreme LPHPower 45985 ROHS3Compliant Right Angle GENERAL PURPOSE Connector Plug, Center Strip Contacts UL94V-0 -40C~105C 30A 250V
PDF
/
Inventory: 8110
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 53.94mm
Technical
Contact Layout, Typical 40 Signal, 4 Power
Number of Ports 1
Connector Style LPHPower
Max Voltage Rating (AC) 250V
UL Flammability Code 94V-0
Contact Gender MALE
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Current Rating 30A
Number of Positions Loaded All
Depth 16.28mm
Orientation Right Angle
Total Number of Contacts 44
Pitch 0.050 1.27mm
Option GENERAL PURPOSE
Mixed Contacts YES
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature POLARIZED, SHROUDED
Number of Rows 2
Color Black
Number of Positions 44
Connector Type Plug, Center Strip Contacts
Termination Solder
Number of Terminations 60
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series EXTreme LPHPower 45985
Packaging Tray
Operating Temperature -40°C~105°C
Physical
Housing Material Polymer
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material Bronze
Supply Chain
Factory Lead Time 8 Weeks
