121A10509X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - DIN 41612
Description
ROHS3Compliant UL Gold Wire Wrap DIN Connector 50Cycles UL94V-0 20mOhm -55C~125C
PDF
/
Inventory: 7041
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Material - Insulation Polybutylene Terephthalate (PBT), Glass Filled
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Wrap
Connector Type Header, Male Pins
Number of Positions 96
Number of Rows 3
DIN Conformance YES
Pitch 0.100 2.54mm
Total Number of Contacts 32
Style R
Number of Positions Loaded 32
Current Rating 2A
Reference Standard UL
Contact Finish Gold
Number Of PCB Rows 2
Body Depth 0.457 inch
Rated Current (Signal) 2A
Contact Resistance 20mOhm
Insulation Resistance 100000000Ohm
PCB Contact Row Spacing 5.08 mm
Durability 50 Cycles
Mating Contact Row Spacing 0.2 inch
Name of Rows Loaded A,C
Dimensions
Length - Termination 0.512 inch
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
