TTC-170
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Audio Transformers
Description
TRANSF TELE COUP 600:600 0MADC
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.421 10.70mm
Technical
DC Resistance (DCR) - Secondary 61Ohm
DC Resistance (DCR) - Primary 47Ohm
Frequency Response ±0.5dB
Impedance - Primary (Ω) 600
Turns Ratio - Primary:Secondary 1:1
Transformer Type Data/Voice Coupling
Insertion Loss (dB) 1.7 dB
Insertion Loss 1.5dB Max @ 1kHz
Frequency Range 300Hz~3.5kHz
Voltage - Isolation 1500VRMS @ 1 Minute
Approval Agency CSA-C22.2 No. 66-M1988, UL1459
Termination Style PC Pin
Reach Compliance Code unknown
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.528Lx0.512W 13.40mmx13.00mm
Series TTC
Published 2015
Packaging Bulk
Operating Temperature 0°C~70°C
Physical
Number of Pins 4
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 20 Weeks
