PE-63588
RoHS
/
Package /
Category Transformers / Current Sense Transformers
Description
CURR SENSE XFMR 20A T/H
PDF
/
Inventory: 4323
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Technical
Packaging Tray
Published 2006
Size / Dimension 0.900Lx0.700W 22.86mmx17.78mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Radial
ECCN Code EAR99
Type Non-Invasive (Solid Core)
Subcategory Other Transformers
Current Rating (Amps) 20A
Frequency 200kHz
Termination Style PC Pin
Approval Agency VDE
Operating Temperature (Max) 130°C
Physical Dimension L22.86XB17.78XH17.78 (mm)
Operating Temperature (Min) -40°C
Inductance 80mH
Lead/Base Style PC Pin
Application POWER
Frequency Range 20kHz~200kHz
Turns Ratio - Primary:Secondary 1:200
Number of Secondary Winding 1
Number of Primary Winding 1
Load Resistance 200Ohm
Current Ratio 200:1
DC Unbalance Current-Max 20000mA
Peak Primary Current 20A
Dimensions
Height 17.78mm
Height Seated (Max) 0.700 17.78mm
Length 22.86mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
