TTC-143-LB
RoHS
/
Package /
Category Transformers / Audio Transformers
Description
Audio Transformers / Signal Transformers 600:600 90mA Connect Phone Coupling Xfmr
PDF
/
Buying Options
Total Price: USD $12.59
Unit Price: USD $12.59465
≥1 USD $12.59465
≥200 USD $5.025781
≥360 USD $4.85773
≥1080 USD $4.775017
Inventory: 1201
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Number of Pins 4
Technical
Published 2006
Part Status Active
Termination Through Hole
ECCN Code EAR99
Current Rating 90mA
Termination Style PC Pin
DC Resistance (DCR) 110Ohm
Max DC Current 90mA
Frequency Range 300Hz~3.5kHz
Transformer Type Impedance Matching
Turns Ratio - Primary:Secondary 1:1.1
Impedance - Primary (Ω) 600
DC Resistance (DCR) - Primary 85Ohm
DC Resistance (DCR) - Secondary 110Ohm
Power Level -45dB~10dB
Dimensions
Height 9mm
Height Seated (Max) 0.350 8.89mm
Length 33mm
Width 20.4mm
Compliance
RoHS Status RoHS Compliant
