PT75161EL

Bourns Inc.
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Specialty Transformers
Description Telecom Transformer 1:2:2 3.5Ohm Prim. DCR 12Term. Gull Wing SMD
PDF
/
Inventory: 5521
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 10.16mm
Length 17.14mm
Height Seated (Max) 0.340 8.63mm

Technical

Return Loss 18 dB
Turns Ratio - Primary:Secondary 1:2.2
Transformer Type TELECOM TRANSFORMER
Lead/Base Style Gull Wing
DC Resistance (DCR) 3.5Ohm
Inductance 10mH
Physical Dimension L17.14XB10.16XH8.63 (mm)
Base Part Number PT7516
Depth 15.24mm
Packing Method TAPE & REEL
Additional Feature HEIGHT DIM. INCLUDES TERMINALS ALSO; TURNS RATIO: 1:2:2
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Size / Dimension 0.675Lx0.400W 17.14mmx10.16mm
Published 2015
Packaging Bulk

Physical

Number of Pins 12
Mounting Type Surface Mount
Mount Surface Mount

Alternative Model
