150J201
RoHS
/
Package /
Category Transformers / Audio Transformers
Description
Audio Transformers / Signal Transformers VOICE TRANSFER
PDF
/
Inventory: 1457
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.500 12.70mm
Height 12.7mm
Technical
DC Resistance (DCR) - Secondary 97Ohm
DC Resistance (DCR) - Primary 74Ohm
Frequency Response 1dB
Impedance - Primary (Ω) 600
Return Loss 18dB
Transformer Type Voice
Insertion Loss (dB) 2 dB
Frequency Range 300Hz~3.4kHz
Current 80mA
Termination Style PC Pin
Shielding Unshielded
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Size / Dimension 1.290Lx1.400W 32.77mmx35.56mm
Series 150
Published 2000
Packaging Bulk
Physical
Mounting Type Through Hole
Mount Through Hole
