AC1005
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Current Sense Transformers
Description
CURR SENSE XFMR 5A T/H
PDF
/
Buying Options
Total Price: USD $4.91
Unit Price: USD $4.9104
≥1 USD $4.9104
≥10 USD $3.97848
≥100 USD $3.216928
≥500 USD $3.01356
≥1000 USD $2.878154
≥3000 USD $2.793498
Inventory: 949
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.937 23.80mm
Technical
Current Ratio 1000:1
Frequency Range 50/60Hz
DC Resistance (DCR) 41.8Ohm
Termination Style PC Pin
Current Rating (Amps) 5A
Type Non-Invasive (Solid Core)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.937Lx0.438W 23.80mmx11.12mm
Series AC
Published 2006
Packaging Tray
Physical
Weight 0.036lb 16.33g
Mounting Type Through Hole
Supply Chain
Factory Lead Time 18 Weeks
