RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Audio Transformers
Description
TRANSFORMER AUDIO 10KCT/1.5KCT
PDF
/
Buying Options
Total Price: USD $20.85
Unit Price: USD $20.8472
≥1 USD $20.8472
Inventory: 56
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.770 19.56mm
Height 19.6mm
Technical
Power Level 150mW
DC Resistance (DCR) - Secondary 110Ohm
DC Resistance (DCR) - Primary 438Ohm
Impedance - Secondary (Ω) 1.5kCT
Frequency Response ±1.5dB
Impedance - Primary (Ω) 10kCT
Turns Ratio - Primary:Secondary 2.58:1
Transformer Type Miniature Epoxy Potted
Insertion Loss (dB) 1.5 dB
Frequency Range 300Hz~50kHz
Voltage - Isolation 500Vrms
Termination Style PC Pin
Shielding Unshielded
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 1.030Lx0.770W 26.16mmx19.56mm
Series 108
Packaging Bulk
Physical
Weight 0.08lb 36.29g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 4 Weeks
