ST4-24B18
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 6VA THRU HOLE
PDF
/
Inventory: 4263
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 33.274mm
Length 41.402mm
Height 33.27mm
Technical
VA Rating 6 VA
Secondary Winding(s) Dual
Output Voltage 2 12V
Voltage - Secondary (Full Load) Parallel 12V Series 24V
Center Tap No
Primary Winding(s) Single
Voltage - Primary 115V
Output Voltage 1 12V
Power - Max 6VA
Current - Output (Max) Parallel 500mA Series 250mA
Max Output Current 250mA
Voltage - Isolation 2500Vrms
Physical Dimension 41.402mm X 33.274mm X 33.274mm
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 6W
Power Rating 6W
HTS Code 8504.31.40.35
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 41.40mm Lx33.27mm W
Series Split Bobbin Plug-In
Published 2007
Physical
Weight 0.44lb 199.58g
Mounting Type Through Hole
Mount Through Hole
