SA571DR2
RoHS
/
Package 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Audio Special Purpose
Description
Consumer Audio Telecommunication Systems GULL WING DUAL Analog Audio Compandor IC -40C~85C TA 0.02MHz 110dB 15V
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.37035
≥1 USD $5.37035
≥10 USD $4.4061
≥100 USD $4.26835
≥500 USD $4.1306
≥1000 USD $3.99285
Inventory: 1550
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 1 week ago)
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Number of Pins 16
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2005
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Applications Consumer Audio, Telecommunication Systems
Technology BIPOLAR
Voltage - Supply 6V~18V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Supply Voltage 15V
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number SA571
Function Compandor
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 18V
Power Supplies 15V
Supply Voltage-Min (Vsup) 6V
Number of Channels 2
Interface Analog
Analog IC - Other Type COMPANDER
Bandwidth 0.02MHz
Supply Current-Max (Isup) 4.8mA
Specifications 110dB
Dimensions
Length 10.3mm
Width 7.5mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
