SDQ12-150-R
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description
SDQ Nonstandard 0.205Lx0.205W 5.20mmx5.20mm 15muH
PDF
/
Buying Options
Total Price: USD $3.08
Unit Price: USD $3.08
≥1 USD $3.08
≥10 USD $2.57488
≥100 USD $2.350656
≥500 USD $2.014848
≥1000 USD $1.846944
≥3000 USD $1.790976
Inventory: 36
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 4
Weight 453.59237mg
Core Material Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2008
Series SDQ
Size / Dimension 0.205Lx0.205W 5.20mmx5.20mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Resistance 576.6mOhm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Shielding Shielded
Depth 5.2mm
Current Rating 658mA
Military Standard Not
Inductance 15 μH
Test Frequency 100kHz
Current 329mA
Max DC Current 779mA
DC Resistance (DCR) - Parallel 576.6mOhm
Inductance - Parallel 15.21 μH
Inductance - Series 60.84 μH
Number of Coils 2
DC Resistance (DCR) - Series 2.31Ohm
Current Rating - Series 329mA
Current Rating - Parallel 658mA
Inductance - Connected In Series 60.84μH
Inductance - Connected In Parallel 15.21μH
Current Saturation - Parallel 779mA
Current Saturation - Series 390mA
Dimensions
Height 0.047 1.19mm
Length 5.2mm
Width 5.207mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
