RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description Obsolete Non-RoHS Compliant Surface Mount 1997 signal transformer -40C~85C ±20% 21mOhm Max 0.235 5.97mm
PDF
/
Inventory: 2058
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Dimensions

Height 0.235 5.97mm

Technical

Inductance - Connected In Parallel 4.7μH
Inductance - Connected In Series 18.8μH
Current Rating - Parallel 3A
Current Rating - Series 1.5A
DC Resistance (DCR) - Series 84mOhm Max
Number of Coils 2
DC Resistance (DCR) - Parallel 21mOhm Max
Shielding Unshielded
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±20%
Size / Dimension 0.450Lx0.450W 11.43mmx11.43mm
Series OCTA-PAC?
Published 1997
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Physical

Package / Case Nonstandard
Mounting Type Surface Mount
