4448R-128L
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description
Active PARALLEL CONNECTED e3 ONE SURFACE Array -55C~125C ±15% 0.01MHz 303mOhm Max
PDF
/
Inventory: 9303
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 0.310 7.87mm
Technical
Current Rating - Parallel 920mA
Current Rating - Series 460mA
DC Resistance (DCR) - Series 1.212Ohm Max
Number of Coils 2
Inductance - Series 400 μH
Inductance - Parallel 100 μH
Special Feature PARALLEL CONNECTED
DC Resistance (DCR) - Parallel 303mOhm Max
Case/Size Code 5450
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Max DC Current 920mA
Test Frequency 0.01MHz
Inductance 100 μH
Construction Rectangular
Depth 13.71mm
Number of Functions 2
Shielding NO
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
Resistance 303mOhm
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 4
Moisture Sensitivity Level (MSL) 5A (24 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±15%
Size / Dimension 0.530Lx0.530W 13.46mmx13.46mm
Series 4448R
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Core Material Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape ONE SURFACE
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
