744870101
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Arrays, Signal Transformers
Description
WE-DD Nonstandard 0.492Lx0.492W 12.50mmx12.50mm 100muH
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.67165
≥1 USD $0.67165
≥10 USD $0.551
≥100 USD $0.5339
≥500 USD $0.5168
≥1000 USD $0.4997
Inventory: 994
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 4
Core Material Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-DD
Size / Dimension 0.492Lx0.492W 12.50mmx12.50mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Resistance 300mOhm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Voltage - Rated DC 80V
Shielding Shielded
Depth 12.5mm
Inductance 100 μH
Current 1.4A
Max DC Current 1.4A
DC Resistance (DCR) - Parallel 300mOhm Max
Inductance Tolerance 20%
RMS Current (Irms) 1.4A
Self Resonant Frequency 4MHz
Inductance - Parallel 100 μH
Inductance - Series 400 μH
Number of Coils 2
Current Rating - Series 700mA
Current Rating - Parallel 1.4A
Inductance - Connected In Series 400μH
Inductance - Connected In Parallel 100μH
Current Saturation - Parallel 2A
Current Saturation - Series 1A
Dimensions
Height 0.335 8.50mm
Length 12.5mm
Width 12.4968mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
