EEF-LS0E181R
RoHS
RoHS compliant
RoHS compliantPackage 2917 (7343 Metric)
Category Capacitors / Aluminum - Polymer Capacitors
Description
CAP ALUM POLY 180UF 20% 2.5V SMD
PDF
/
Inventory: 7139
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4.3mm
Length 7.3mm
Height Seated (Max) 0.047 1.20mm
Technical
Ripple Current @ High Frequency 7.5A @ 100kHz
Lifetime @ Temp 2000 Hrs @ 105°C
Rated (DC) Voltage (URdc) 2.5V
Polarity POLARIZED
ESR (Equivalent Series Resistance) 6mOhm
Capacitance 180μF
Voltage - Rated 2.5V
Applications General Purpose
Type Polymer
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Tolerance ±20%
Size / Dimension 0.287Lx0.169W 7.30mmx4.30mm
Series SP-Cap LS
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature -55°C~105°C
Physical
Surface Mount Land Size 0.287Lx0.169W 7.30mmx4.30mm
Package / Case 2917 (7343 Metric)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
