25SEK120M
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum - Polymer Capacitors
Description
CAP ALUM POLY 120UF 20% 25V T/H
PDF
/
Buying Options
Total Price: USD $1.4
Unit Price: USD $1.3992
≥1 USD $1.3992
≥10 USD $1.04808
≥100 USD $0.783464
≥500 USD $0.551725
≥1000 USD $0.496549
≥3000 USD $0.478166
Inventory: 1101
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole
Package / Case Radial, Can
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series OS-CON?, SEK
Size / Dimension 0.315Dia 8.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Type Polymer
Applications General Purpose
Capacitance 120μF
Voltage - Rated DC 25V
ESR (Equivalent Series Resistance) 24mOhm
Lead Spacing 0.138 3.50mm
Lifetime @ Temp 1000 Hrs @ 125°C
Ripple Current @ Low Frequency 50.5mA @ 120Hz
Ripple Current @ High Frequency 1.01A @ 100kHz
Dimensions
Height Seated (Max) 0.276 7.00mm
Compliance
RoHS Status ROHS3 Compliant
