PLV1J270MDL1 image
Favorite
PLV1J270MDL1 image
Favorite

PLV1J270MDL1

Nichicon
RoHS
RoHS RoHS compliant
Package Radial, Can
Category Capacitors / Aluminum - Polymer Capacitors
Description Radial Can PLV 63V 27muF ±20% 0.315Dia 8.00mm
PDF
/
Buying Options
Total Price: USD $2.03
Unit Price: USD $2.0328
≥1 USD $2.0328
≥10 USD $1.56288
≥100 USD $1.190156
≥500 USD $0.837302
≥1000 USD $0.777498
≥3000 USD $0.762546
Inventory: 229
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 17 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Terminal Shape WIRE

Technical

Operating Temperature -55°C~105°C
Packaging Bulk
Published 2009
Series PLV
Size / Dimension 0.315Dia 8.00mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Radial
ECCN Code EAR99
Type Polymer
Terminal Finish Tin (Sn)
Applications General Purpose
HTS Code 8532.22.00
Capacitance 27μF
Voltage - Rated DC 63V
Lead Pitch 3.5mm
ESR (Equivalent Series Resistance) 33mOhm
Polarity Polar
Lead Spacing 0.138 3.50mm
Lead Diameter 600 μm
Voltage 63V
Lifetime @ Temp 3000 Hrs @ 105°C
Leakage Current 340μA
Ripple Current 2.1A
Life (Hours) 3000 hours
Ripple Current @ High Frequency 2.1A @ 100kHz
Dissipation Factor 0.12 %

Dimensions

Diameter 8mm
Height 12mm
Height Seated (Max) 0.472 12.00mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
