63PZA27M8X12.5
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum - Polymer Capacitors
Description
CAP ALUM POLY 27UF 20% 63V T/H
PDF
/
Buying Options
Total Price: USD $3.17
Unit Price: USD $3.169341
≥1 USD $3.169341
≥200 USD $1.264323
≥500 USD $1.22231
≥1000 USD $1.201304
Inventory: 3755
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.492 12.50mm
Technical
Ripple Current @ High Frequency 2.1A @ 100kHz
Ripple Current @ Low Frequency 105mA @ 120Hz
Life (Hours) 3000 hours
Ripple Current 2.1A
Lifetime @ Temp 3000 Hrs @ 105°C
Lead Spacing 0.138 3.50mm
ESR (Equivalent Series Resistance) 33mOhm
Lead Pitch 3.5052mm
Capacitance 27μF
Voltage - Rated 63V
Applications Automotive
Type Polymer
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±20%
Size / Dimension 0.315Dia 8.00mm
Series PZA
Packaging Bulk
Operating Temperature -55°C~105°C
Physical
Package / Case Radial, Can
Mounting Type Through Hole
Mount Through Hole
