860010475016
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can WCAP-ATG8 25V 820muF ±20% 0.394Dia 10.00mm
PDF
/
Buying Options
Total Price: USD $0.48
Unit Price: USD $0.477733
≥1 USD $0.477733
≥10 USD $0.450691
≥100 USD $0.425179
≥500 USD $0.401113
≥1000 USD $0.378405
Inventory: 7650
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Material Aluminium
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Box (TB)
Series WCAP-ATG8
Size / Dimension 0.394Dia 10.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Applications General Purpose
Voltage - Rated 25V
Capacitance 820μF
Voltage - Rated DC 25V
Lead Pitch 5.0038mm
Polarity Polar
Lead Spacing 0.197 5.00mm
Lifetime @ Temp 2000 Hrs @ 85°C
Ripple Current 891mA
Polarization Polar
Life (Hours) 2000 hours
Ripple Current @ Low Frequency 891mA @ 120Hz
Ripple Current @ High Frequency 1.22958A @ 100kHz
Dimensions
Diameter 10mm
Height 20mm
Height Seated (Max) 0.846 21.50mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
