B43252B2477M
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - Snap-In
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can - Snap-In ALUMINUM ELECTROLYTIC CAPACITOR B43252 200V 470muF ±20% 1.181Dia 30.00mm
PDF
/
Inventory: 7332
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case Radial, Can - Snap-In
Surface Mount NO
Dielectric Material ALUMINUM (WET)
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Series B43252
Size / Dimension 1.181Dia 30.00mm
Tolerance ±20%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Applications General Purpose
Voltage - Rated 200V
Capacitance 470μF
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Lead Spacing 0.394 10.00mm
Rated (DC) Voltage (URdc) 200V
Lifetime @ Temp 2000 Hrs @ 105°C
Leakage Current 1.88mA
Polarization Polar
Tan Delta 0.12
Ripple Current @ Low Frequency 1.44A @ 120Hz
Ripple Current @ High Frequency 2.232A @ 20kHz
Dimensions
Diameter 30mm
Height Seated (Max) 1.063 27.00mm
Length 25mm
Compliance
RoHS Status ROHS3 Compliant
