B43508B2477M82
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - Snap-In
Category Capacitors / Aluminum Electrolytic Capacitors
Description
B43508 Radial Can - Snap-In aluminum electrolytic capacitor 0.984Dia 25.00mm ±20% 470muF 200V
PDF
/
Inventory: 8317
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can - Snap-In
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Series B43508
Size / Dimension 0.984Dia 25.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Snap in
Applications General Purpose
Voltage - Rated 200V
Capacitance 470μF
Lead Pitch 10.0076mm
ESR (Equivalent Series Resistance) 250mOhm @ 100Hz
Lead Spacing 0.394 10.00mm
Lifetime @ Temp 3000 Hrs @ 105°C
Ripple Current 1.35A
Polarization Polar
Life (Hours) 3000 hours
Impedance 340mOhm
Ripple Current @ Low Frequency 1.35A @ 100Hz
Dimensions
Diameter 25mm
Height 30mm
Height Seated (Max) 1.268 32.20mm
Compliance
RoHS Status ROHS3 Compliant
