25ZLK1000M10X25
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can ALUMINUM ELECTROLYTIC CAPACITOR ZLK 25V 1000muF ±20% 0.394Dia 10.00mm
PDF
/
Buying Options
Total Price: USD $0.85
Unit Price: USD $0.853754
≥1 USD $0.853754
≥10 USD $0.805431
≥100 USD $0.759837
≥500 USD $0.716832
≥1000 USD $0.676258
Inventory: 1167
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Number of Pins 2
Dielectric Material Aluminium
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Published 2004
Series ZLK
Size / Dimension 0.394Dia 10.00mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Radial
Terminal Finish Tin (Sn)
Applications General Purpose
Capacitance 1000μF
Voltage - Rated DC 25V
Lead Pitch 5mm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Lead Spacing 0.197 5.00mm
Lead Diameter 600 μm
Voltage 25V
Lifetime @ Temp 5000 Hrs @ 105°C
Leakage Current 10nA
Ripple Current 3.16A
Polarization Polar
Life (Hours) 5000 hours
Impedance 24mOhm
Ripple Current @ Low Frequency 948mA @ 120Hz
Ripple Current @ High Frequency 3.16A @ 100kHz
Dimensions
Diameter 10mm
Height 25mm
Height Seated (Max) 1.063 27.00mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
