25WXA1000MG412.5X16
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
WXA ALUMINUM ELECTROLYTIC CAPACITOR Radial Can aluminum electrolytic capacitor 0.492Dia 12.50mm ±20% 1000muF 25V
PDF
/
Buying Options
Total Price: USD $0.32
Unit Price: USD $0.316028
≥1 USD $0.316028
≥200 USD $0.122296
≥500 USD $0.118003
≥1000 USD $0.115876
Inventory: 6575
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Terminal Shape WIRE
Dielectric Material ALUMINUM (WET)
Technical
Operating Temperature -55°C~105°C
Packaging Tape & Box (TB)
Series WXA
Size / Dimension 0.492Dia 12.50mm
Tolerance ±20%
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin (Sn)
Applications Automotive
Voltage - Rated 25V
Capacitance 1000μF
Terminal Pitch 5mm
Lead Pitch 5.0038mm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Lead Spacing 0.197 5.00mm
Rated (DC) Voltage (URdc) 25V
Lifetime @ Temp 2000 Hrs @ 105°C
Leakage Current 0.25mA
Ripple Current 670mA
Polarization Polar
Life (Hours) 2000 hours
Tan Delta 0.16
Ripple Current @ Low Frequency 670mA @ 120Hz
Ripple Current @ High Frequency 804mA @ 10kHz
Dimensions
Diameter 12.5mm
Height Seated (Max) 0.689 17.50mm
Length 16mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
