25YXH3300MEFCGC16X31.5
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
YXH Radial Can aluminum electrolytic capacitor 0.630Dia 16.00mm ±20% 3300muF 25V
PDF
/
Inventory: 8661
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Box (TB)
Series YXH
Size / Dimension 0.630Dia 16.00mm
Tolerance ±20%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Applications General Purpose
Voltage - Rated 25V
HTS Code 8532.24.0060
Capacitance 3300μF
Lead Pitch 7.493mm
Lead Spacing 0.295 7.50mm
Lifetime @ Temp 10000 Hrs @ 105°C
Ripple Current 2.4A
Polarization Polar
Life (Hours) 10000 hours
Impedance 17mOhm
Ripple Current @ Low Frequency 2.415A @ 120Hz
Ripple Current @ High Frequency 3.45A @ 100kHz
Dimensions
Height Seated (Max) 1.319 33.50mm
Compliance
RoHS Status ROHS3 Compliant
