SK332M025ST
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can ALUMINUM ELECTROLYTIC CAPACITOR SK 25V 3300muF ±20% 0.630Dia 16.00mm
PDF
/
Buying Options
Total Price: USD $4
Unit Price: USD $3.9952
≥1 USD $3.9952
≥10 USD $3.06768
≥100 USD $2.770768
≥500 USD $2.384184
≥1000 USD $1.868698
≥3000 USD $1.73983
Inventory: 1114
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 25 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Terminal Shape WIRE
Dielectric Material ALUMINUM (WET)
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2005
Series SK
Size / Dimension 0.630Dia 16.00mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Radial
ECCN Code EAR99
Terminal Finish Tin (Sn)
Applications General Purpose
Capacitance 3300μF
Voltage - Rated DC 25V
Lead Pitch 7.5mm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Lead Length 15mm
ESR (Equivalent Series Resistance) 100mOhm
Polarity POLARIZED
Lead Spacing 0.295 7.50mm
Lead Diameter 800 μm
Lifetime @ Temp 2000 Hrs @ 85°C
Leakage Current 0.825mA
Ripple Current 1.95A
Life (Hours) 2000 hours
Tan Delta 0.20
Dissipation Factor 14 %
Dimensions
Diameter 16mm
Height 32mm
Height Seated (Max) 1.339 34.00mm
Compliance
RoHS Status ROHS3 Compliant
