10RX30470MT810X12.5
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
RX30 Radial Can aluminum electrolytic capacitor 0.394Dia 10.00mm ±20% 470muF 10V
PDF
/
Inventory: 1108
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.571 14.50mm
Technical
Ripple Current @ Low Frequency 465mA @ 120Hz
Impedance 150mOhm
Life (Hours) 2000 hours
Polarization Polar
Ripple Current 465mA
Lifetime @ Temp 2000 Hrs @ 130°C
Lead Spacing 0.197 5.00mm
Lead Pitch 5.0038mm
Capacitance 470μF
Voltage - Rated 10V
Applications Automotive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Tolerance ±20%
Size / Dimension 0.394Dia 10.00mm
Series RX30
Packaging Tape & Box (TB)
Operating Temperature -40°C~130°C
Physical
Package / Case Radial, Can
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 20 Weeks
