EEU-FM1A471BJ
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can FM 10V 470muF ±20% 0.315Dia 8.00mm
PDF
/
Buying Options
Total Price: USD $0.39
Unit Price: USD $0.3872
≥1 USD $0.3872
≥10 USD $0.25432
≥100 USD $0.187088
≥500 USD $0.152416
≥1000 USD $0.120331
Inventory: 1124
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Box (TB)
Published 2006
Series FM
Size / Dimension 0.315Dia 8.00mm
Tolerance ±20%
Feature General Purpose
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Radial
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Applications General Purpose
Voltage - Rated 10V
Capacitance 470μF
Voltage - Rated DC 10V
Lead Pitch 5.0038mm
ESR (Equivalent Series Resistance) 56mOhm
Polarity Polar
Lead Spacing 0.197 5.00mm
Lifetime @ Temp 3000 Hrs @ 105°C
Ripple Current 950mA
Polarization Polar
Life (Hours) 3000 hours
Impedance 56mOhms
Ripple Current @ Low Frequency 712.5mA @ 120Hz
Ripple Current @ High Frequency 950mA @ 100kHz
Dissipation Factor 0.19 %
Lead/Base Style Straight
Dimensions
Diameter 8mm
Height 11.5mm
Height Seated (Max) 0.512 13.00mm
Length 11.5mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
