EEE-HP1H4R7P
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - SMD
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can - SMD ALUMINUM ELECTROLYTIC CAPACITOR HB 50V 4.7muF ±20% 0.248Dia 6.30mm
PDF
/
Buying Options
Total Price: USD $0.53
Unit Price: USD $0.528
≥1 USD $0.528
≥10 USD $0.35288
≥100 USD $0.280896
≥500 USD $0.232056
≥1000 USD $0.18128
Inventory: 1080
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Radial, Can - SMD
Terminal Shape FLAT
Dielectric Material ALUMINUM (WET)
Surface Mount Land Size 0.260Lx0.260W 6.60mmx6.60mm
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Published 2005
Series HB
Size / Dimension 0.248Dia 6.30mm
Tolerance ±20%
JESD-609 Code e3/e6
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish TIN/TIN BISMUTH
Applications Automotive
Capacitance 4.7μF
Voltage - Rated DC 50V
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Size Code 2626
Lifetime @ Temp 2000 Hrs @ 105°C
Leakage Current 3μA
Ripple Current 23mA
Polarization Bi-Polar
Life (Hours) 2000 hours
Ripple Current @ Low Frequency 23mA @ 120Hz
Ripple Current @ High Frequency 39.1mA @ 10kHz
Dissipation Factor 0.24 %
Dimensions
Diameter 6.3mm
Height 7.8mm
Height Seated (Max) 0.240 6.10mm
Width 6.6mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Ratings AEC-Q200
