EEE-HC1E330P
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - SMD
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can - SMD ALUMINUM ELECTROLYTIC CAPACITOR HC 25V 33muF ±20% 0.248Dia 6.30mm
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.396
≥1 USD $0.396
≥10 USD $0.264
≥100 USD $0.19448
≥500 USD $0.158312
≥1000 USD $0.125013
Inventory: 1086
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 6.6mm
Length 7.8mm
Height Seated (Max) 0.228 5.80mm
Height 5.8mm
Diameter 6.3mm
Technical
Ripple Current (AC) 65mA
Ripple Current @ High Frequency 110.5mA @ 10kHz
Ripple Current @ Low Frequency 65mA @ 120Hz
Tan Delta 0.16
Life (Hours) 3000 hours
Polarization Polar
Ripple Current 65mA
Leakage Current 3μA
Lifetime @ Temp 3000 Hrs @ 105°C
Voltage 25V
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Lead Pitch 1.8mm
Voltage - Rated DC 25V
Capacitance 33μF
Applications Automotive
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3/e6
Tolerance ±20%
Size / Dimension 0.248Dia 6.30mm
Series HC
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C
Physical
Surface Mount Land Size 0.260Lx0.260W 6.60mmx6.60mm
Dielectric Material ALUMINUM (WET)
Number of Pins 2
Terminal Shape FLAT
Package / Case Radial, Can - SMD
Mounting Type Surface Mount
Mount PCB, Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 17 Weeks
