25TZV33M6.3X6.1
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - SMD
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can - SMD ALUMINUM ELECTROLYTIC CAPACITOR TZV 25V 33muF ±20% 0.248Dia 6.30mm
PDF
/
Buying Options
Total Price: USD $0.41
Unit Price: USD $0.4136
≥1 USD $0.4136
≥10 USD $0.2596
≥100 USD $0.190784
≥500 USD $0.168608
≥1000 USD $0.130926
Inventory: 1833
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 6.6mm
Height Seated (Max) 0.240 6.10mm
Height 6.1mm
Diameter 6.3mm
Technical
Ripple Current (AC) 250mA
Ripple Current @ High Frequency 250mA @ 100kHz
Ripple Current @ Low Frequency 80mA @ 120Hz
Impedance 360mOhm
Tan Delta 0.14
Life (Hours) 2000 hours
Polarization Polar
Ripple Current 250mA
Leakage Current 3μA
Lifetime @ Temp 2000 Hrs @ 105°C
Voltage 25V
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Packing Method TR
Voltage - Rated DC 25V
Capacitance 33μF
Applications Automotive
Terminal Finish Tin/Bismuth (Sn/Bi)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e6
Tolerance ±20%
Size / Dimension 0.248Dia 6.30mm
Series TZV
Packaging Cut Tape (CT)
Operating Temperature -55°C~105°C
Physical
Surface Mount Land Size 0.260Lx0.260W 6.60mmx6.60mm
Dielectric Material Aluminium
Number of Pins 2
Terminal Shape WRAPAROUND
Package / Case Radial, Can - SMD
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 20 Weeks
