EEE-HB1C470P
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - SMD
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can - SMD ALUMINUM ELECTROLYTIC CAPACITOR HB 16V 47muF ±20% 0.248Dia 6.30mm
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.396
≥1 USD $0.396
≥10 USD $0.26048
≥100 USD $0.191664
≥500 USD $0.156024
≥1000 USD $0.123182
Inventory: 4758
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mounting Type Surface Mount
Package / Case Radial, Can - SMD
Terminal Shape FLAT
Dielectric Material ALUMINUM (WET)
Surface Mount Land Size 0.260Lx0.260W 6.60mmx6.60mm
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Published 2011
Series HB
Size / Dimension 0.248Dia 6.30mm
Tolerance ±20%
JESD-609 Code e3/e6
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish TIN/TIN BISMUTH
Applications Automotive
Voltage - Rated 16V
Capacitance 47μF
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Rated (DC) Voltage (URdc) 16V
Size Code 2626
Lifetime @ Temp 2000 Hrs @ 105°C
Leakage Current 0.00752mA
Polarization Polar
Tan Delta 0.16
Ripple Current @ Low Frequency 70mA @ 120Hz
Ripple Current @ High Frequency 119mA @ 10kHz
Dimensions
Height Seated (Max) 0.228 5.80mm
Length 7.8mm
Width 6.6mm
Compliance
RoHS Status RoHS Compliant
Ratings AEC-Q200
