EEE-FT1V470AR
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - SMD
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can - SMD ALUMINUM ELECTROLYTIC CAPACITOR FT 35V 47muF ±20% 0.197Dia 5.00mm
PDF
/
Buying Options
Total Price: USD $0.48
Unit Price: USD $0.4752
≥1 USD $0.4752
≥10 USD $0.31944
≥100 USD $0.253968
≥500 USD $0.209792
≥1000 USD $0.163874
Inventory: 1268
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mounting Type Surface Mount
Package / Case Radial, Can - SMD
Terminal Shape FLAT
Dielectric Material ALUMINUM
Surface Mount Land Size 0.209Lx0.209W 5.30mmx5.30mm
Technical
Operating Temperature -55°C~105°C
Packaging Tape & Reel (TR)
Published 2011
Series FT
Size / Dimension 0.197Dia 5.00mm
Tolerance ±20%
JESD-609 Code e3/e6
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish TIN/TIN BISMUTH
Applications Automotive
Voltage - Rated 35V
Capacitance 47μF
Packing Method TR, 15 Inch
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
ESR (Equivalent Series Resistance) 360mOhm @ 100kHz
Rated (DC) Voltage (URdc) 35V
Size Code 2121
Lifetime @ Temp 2000 Hrs @ 105°C
Leakage Current 0.01645mA
Polarization Polar
Tan Delta 0.12
Ripple Current @ Low Frequency 156mA @ 120Hz
Ripple Current @ High Frequency 240mA @ 100kHz
Dimensions
Diameter 5mm
Height Seated (Max) 0.240 6.10mm
Length 5.8mm
Compliance
RoHS Status RoHS Compliant
Ratings AEC-Q200
