EEE-HB1V470AP
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - SMD
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can - SMD ALUMINUM ELECTROLYTIC CAPACITOR HB 35V 47muF ±20% 0.315Dia 8.00mm
PDF
/
Buying Options
Total Price: USD $0.72
Unit Price: USD $0.7216
≥1 USD $0.7216
≥10 USD $0.52096
≥100 USD $0.455664
≥500 USD $0.371272
Inventory: 571
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mounting Type Surface Mount
Package / Case Radial, Can - SMD
Terminal Shape FLAT
Dielectric Material ALUMINUM (WET)
Surface Mount Land Size 0.327Lx0.327W 8.30mmx8.30mm
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Published 2011
Series HB
Size / Dimension 0.315Dia 8.00mm
Tolerance ±20%
JESD-609 Code e3/e6
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish TIN/TIN BISMUTH
Applications Automotive
Voltage - Rated 35V
Capacitance 47μF
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Rated (DC) Voltage (URdc) 35V
Size Code 3333
Lifetime @ Temp 2000 Hrs @ 105°C
Leakage Current 0.01645mA
Polarization Polar
Tan Delta 0.14
Ripple Current @ Low Frequency 98mA @ 120Hz
Ripple Current @ High Frequency 166.6mA @ 10kHz
Dimensions
Height Seated (Max) 0.402 10.20mm
Length 8.3mm
Width 8.3mm
Compliance
RoHS Status RoHS Compliant
Ratings AEC-Q200
