ECA-1CM220
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can M 16V 22muF ±20% 0.197Dia 5.00mm
PDF
/
Buying Options
Total Price: USD $0.2
Unit Price: USD $0.2024
≥1 USD $0.2024
≥10 USD $0.13288
≥100 USD $0.067232
≥500 USD $0.042944
≥1000 USD $0.037347
≥3000 USD $0.035473
Inventory: 8599
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case Radial, Can
Terminal Shape WIRE
Number of Pins 2
Dielectric Material Aluminium
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2011
Series M
Size / Dimension 0.197Dia 5.00mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Radial
ECCN Code EAR99
Terminal Finish Tin (Sn)
Applications General Purpose
Capacitance 22μF
Voltage - Rated DC 16V
Voltage - Rated AC 16V
Lead Pitch 2mm
Lead Spacing 0.079 2.00mm
Lead Diameter 500 μm
Voltage 16V
Lifetime @ Temp 2000 Hrs @ 85°C
Leakage Current 3μA
Ripple Current 75mA
Polarization Polar
Life (Hours) 2000 hours
Tan Delta 0.2
Ripple Current @ Low Frequency 75mA @ 120Hz
Ripple Current @ High Frequency 127.5mA @ 10kHz
Dissipation Factor 0.2 %
Lead/Base Style Straight
Ripple Current (AC) 75mA
Dimensions
Diameter 5mm
Height 11mm
Height Seated (Max) 0.472 12.00mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
