CPE-163
RoHS
RoHS compliant
RoHS compliantPackage /
Category Audio Products / Alarms, Buzzers, and Sirens
Description
AUDIO PIEZO TRANSDUCER 30V
PDF
/
Buying Options
Total Price: USD $0.61
Unit Price: USD $0.6072
≥1 USD $0.6072
≥10 USD $0.506
≥100 USD $0.468864
≥500 USD $0.44176
≥1000 USD $0.430144
Inventory: 1253
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mounting Type Custom
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2011
Series CPE
Size / Dimension 0.512Dia 13.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Leads
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Voltage - Rated 10V
Technology Piezo
Operating Supply Current 10mA
Operating Mode Single Tone
Input Type Peak-Peak Signal
Current - Supply 10mA
Voltage Range 30V Max
Washable No
Port Location Top
Sound Pressure Level (SPL) 80dB @ 10V, 10cm
Driver Circuitry Transducer, Externally Driven
Dimensions
Height 3mm
Height Seated (Max) 0.118 3.00mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
