19028245A
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / AC Fans
Description
FAN AXIAL 172X50.8MM 115V MR2B3
PDF
/
Buying Options
Total Price: USD $69.09
Unit Price: USD $69.0888
≥1 USD $69.0888
≥10 USD $62.50816
≥100 USD $54.28309
≥500 USD $50.99336
≥1000 USD $44.4136
Inventory: 34
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Package / Case Axial
Weight 1.8lbs 816.5g
Material - Frame Aluminum
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2011
Series Major AC
Size / Dimension Rectangular/Rounded - 172mm Lx150mm H
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Terminals
Max Operating Temperature 158°C
Min Operating Temperature 14°C
Power (Watts) 31.00W
Voltage - Rated 115VAC
Current Rating (Amps) 0.260A
Max Power Dissipation 31W
Current Rating 260mA
Approval Agency CE, cUL, UL
Lifetime @ Temp 51000 Hrs @ 40°C
Life (Hours) 51000 hours
RPM 3400 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 235.0 CFM (6.58m3/min)
Noise 55.8 dB(A)
Static Pressure 0.769 in H2O (191.5 Pa)
Dimensions
Width 50.80mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
