19020189A
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / AC Fans
Description
FAN AXIAL 254X89MM 115VAC CLE2T2
PDF
/
Buying Options
Total Price: USD $87.85
Unit Price: USD $87.8504
≥1 USD $87.8504
≥10 USD $79.486
≥100 USD $69.027552
≥500 USD $64.844208
≥1000 USD $56.477168
Inventory: 265
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Static Pressure 0.331 in H2O (82.4 Pa)
Noise 49.2 dB(A)
Air Flow 550.0 CFM (15.40m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 1650 RPM
Lifetime @ Temp 54000 Hrs @ 40°C
Approval Agency CE, cUL, UL
Current Rating 500mA
Max Power Dissipation 61W
Current Rating (Amps) 0.5A
Voltage - Rated 115VAC
Power (Watts) 61.0W
Termination 2 Terminals
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Round - 254mm Dia
Series Caravel AC
Published 2012
Operating Temperature -22~140°F -30°C~60°C
Physical
Material - Blade Plastic
Material - Frame Aluminum
Weight 4.4lbs 2kg
Package / Case Axial
Supply Chain
Factory Lead Time 18 Weeks
