BFB1624M
RoHS
/
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN BLOWER 159X40MM 24VDC WIRE
PDF
/
Inventory: 8068
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Flanges, Wire
Housing Material Plastic
Weight 1.3lbs 589.7g
Material - Frame Plastic
Material - Blade Plastic
Technical
Published 2011
Series BFB
Size / Dimension Rectangular/Rounded - 159mm Lx165mm H
Feature Locked Rotor Protection
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Power (Watts) 13.4W
Voltage - Rated 24VDC
Power Rating 13.44W
Voltage - Rated DC 24V
Current Rating (Amps) 0.560A
Max Power Dissipation 13.4W
Current Rating 560mA
Approval Agency CE, CSA, UL, VDE
RPM 2000 RPM
Bearing Type Ball
Fan Type Blower
Air Flow 55.1 CFM (1.54m3/min)
Noise 54.5 dB(A)
Voltage Range 14V~26.4VDC
Static Pressure 1.102 in H2O (274.5 Pa)
Dimensions
Width 40.00mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
