AED36US48
RoHS
/
Package /
Category Power Supplies - External/Internal (Off-Board) / AC DC Desktop, Wall Adapters
Description
AC/DC DESKTOP ADAPTER 48V 36W
PDF
/
Buying Options
Total Price: USD $168.54
Unit Price: USD $168.54
≥1 USD $168.54
≥10 USD $159
≥100 USD $150
Inventory: 8620
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Technical
Max Input Voltage (AC) 264V
Min Input Voltage (AC) 90V
Nominal Output Voltage 48V
Output Connector Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 12.0mm
Input Connector IEC 320-C8
Cord Length 48 1.22m
Region Utilized International
Form Desktop (Class II)
Max Output Power 36W
Current - Output 1 750mA
Max Input Voltage 264V
Min Input Voltage 90V
Output Power 36W
Input Type Cord (Sold Separately)
Output Current 750mA
Voltage - Input 90V~264VAC
Polarization Positive Center
Voltage - Output 1 48V
Max Output Current 750mA
Efficiency 85%
Number of Outputs 1
Frequency 63Hz
Power Rating 36W
Applications ITE (Commercial)
Connector Type Plug
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 4.33Lx1.97W x 0.79 H 110.0mmx50.0mmx20.0mm
Series AED36 (36W)
Published 2007
Operating Temperature 0°C~60°C
Physical
Mount Plug-In
Supply Chain
Factory Lead Time 15 Weeks
