TMT 15212
RoHS
RoHS compliant
RoHS compliantPackage 5-DIP Module
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER +/-12V 15W
PDF
/
Inventory: 1709
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDMA-X6
Number of Outputs 2
Approval Agency CB, CE, cULus, cURus
Efficiency 83%
Output Voltage 12V
Voltage - Output 1 12V
Input Voltage-Nom 115V
Trim/Adjustable Output NO
Current - Output (Max) 625mA 625mA
Voltage - Input 85V~264VAC 85V~370VDC
Voltage - Output 2 -12V
Total Power Output-Max 15W
Load Regulation 500mV
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position DUAL
Technology HYBRID
Power (Watts) 15W
Applications ITE (Commercial), Medical
Type Enclosed
ECCN Code EAR99
Number of Terminations 6
Part Status Not For New Designs
Feature Universal Input
Size / Dimension 2.17Lx1.77W x 0.94 H 55.0mmx45.0mmx24.0mm
Series TMT (15W)
Published 2007
Operating Temperature -25°C~50°C With Derating
Compliance
RoHS Status ROHS3 Compliant
Physical
Surface Mount NO
Package / Case 5-DIP Module
Mounting Type Through Hole
