VYB20W-Q48-D12-H
RoHS
/
Package 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC CONVERT +/-12V 833MA THRU
PDF
/
Inventory: 4881
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 6-DIP Module
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2013
Series VYB20W (20W)
Size / Dimension 2.00Lx1.18W x 0.89 H 50.8mmx30.0mmx22.5mm
Feature Remote On/Off, UVLO
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 20W
Number of Outputs 2
Efficiency 87%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 75V
Max Output Current 833mA
Voltage - Output 1 12V
Voltage - Input (Min) 18V
Current - Output (Max) 833mA 833mA
Control Features Enable, Active High
Voltage - Output 2 -12V
Dimensions
Height 22.606mm
Compliance
RoHS Status RoHS Compliant
