KMD15-55
RoHS
RoHS compliant
RoHS compliantPackage 9-DIP Module, 5 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description
PWR SUP MEDICAL +5V/-5V 1.5A 15W
PDF
/
Buying Options
Total Price: USD $53.02
Unit Price: USD $53.02
≥1 USD $53.02
≥10 USD $43.076
Inventory: 141
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Width 45.466mm
Length 64.008mm
Height 23.368mm
Technical
Max Input Voltage (AC) 264V
Min Input Voltage (AC) 90V
Load Regulation 1%
Line Regulation 0.5%
Current - Output 2 1.5A
Max Output Power 15W
Current - Output 1 1.5A
Max Input Voltage 264V
Min Input Voltage 90V
Voltage - Output 2 -5V
Output Power 15W
Output Current 1.5A
Voltage - Input 90V~264VAC 100V~375VDC
Current - Output (Max) 1.5A 1.5A
Max Current Rating 220mA
Voltage - Output 1 5V
Max Output Current 1.5A
Output Voltage 5V
Efficiency 78%
Approval Agency CE, EN, IEC, UL
Number of Outputs 2
Depth 64mm
Max Power Dissipation 15W
Power Rating 15W
Power (Watts) 15W
Applications Medical
Min Operating Temperature -25°C
Max Operating Temperature 70°C
Type Enclosed
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature OCP, OVP
Size / Dimension 2.52Lx1.80W x 0.93 H 64.0mmx45.6mmx23.5mm
Series KM (15W)
Published 2009
Operating Temperature -25°C~70°C With Derating
Physical
Weight 0.265lb 120.2g
Number of Pins 9
Package / Case 9-DIP Module, 5 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 14 Weeks
