BP5068A24
RoHS
RoHS compliant
RoHS compliantPackage 12-SIP Module, 7 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description
AC/DC CONVERTER -24V 14W
PDF
/
Inventory: 9008
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 21.59mm
Technical
Min Supply Voltage (AC) 85V
Load Regulation 550mV
Line Regulation 230mV
Max Supply Voltage (AC) 115V
Output Power 14.4W
Output Current 600mA
Voltage - Input 85V~115VAC
Min Supply Voltage -162V
Max Supply Voltage -120V
Trim/Adjustable Output NO
Input Voltage-Nom -141V
Voltage - Output 1 -24V
Max Output Current 600mA
Output Voltage 24V
Efficiency 88%
Qualification Status Not Qualified
Number of Outputs 1
Time@Peak Reflow Temperature-Max (s) 10
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 14W
Subcategory Power Supply Modules
Power (Watts) 14W
Applications ITE (Commercial)
Terminal Finish Tin/Copper (Sn/Cu)
Type Enclosed
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e2
Size / Dimension 1.36Lx0.44W x 0.85 H 34.5mmx11.3mmx21.5mm
Series BP5068
Published 2010
Packaging Bulk
Operating Temperature -20°C~80°C With Derating
Physical
Number of Pins 7
Package / Case 12-SIP Module, 7 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 15 Weeks
