AIF04ZPFC-01NT

Artesyn Embedded Power
RoHS
/
Package 34-DIP Module, 24 Leads
Category Power Supplies - Board Mount / AC DC Converters
Description AC/DC CONVERTER 380V 1600W
PDF
/
Inventory: 5640
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Height 13.97mm

Technical

Isolation Isolated
Output Power 1.6kW
Voltage - Input 85V~264VAC
Trim/Adjustable Output YES
Max Output Current 4.2A
Output Voltage 380V
Efficiency 95%
Approval Agency cUL, TUV, UL
Qualification Status Not Qualified
Number of Outputs 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Depth 61mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position UNSPECIFIED
Technology HYBRID
Max Power Dissipation 1.6kW
Power (Watts) 1600W
Applications ITE (Commercial)
Terminal Finish TIN LEAD
Type Enclosed
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature OTP, OVP
JESD-609 Code e0
Size / Dimension 4.60Lx2.40W x 0.55 H 116.8mmx61.0mmx14.0mm
Series AIF-PFC (1600W)
Published 2010
Operating Temperature -20°C~100°C

Physical

Number of Pins 24
Package / Case 34-DIP Module, 24 Leads
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 18 Weeks
