3600S-1-103

Bourns Inc.
RoHS
/
Package /
Category Potentiometers, Variable Resistors / Value Display Potentiometers
Description VALUE DISPLY POT 10K 1.5W PNL MT
PDF
/
Inventory: 7150
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Dimensions

Height 25.4mm

Technical

Ganging Number 1
Number of Characters 10
Actuator Orientation VERTICAL
Number of Turns 10
Adjustment Type Rotary
Rated Temperature 25°C
Lead Diameter 0.724 mm
Lead Length 4.76mm
Operating Temperature (Min) 1°C
Actuator Type KNOB
Operating Temperature (Max) 85°C
Termination Style Solder Lug
Base Part Number 3600S
Reach Compliance Code unknown
Resistor Type POTENTIOMETER
Construction Bushing
Technology WIRE WOUND
Max Power Dissipation 1.5W
Power Rating 1.5W
Subcategory Variable Resistors
Voltage - Rated 385V
Composition Wirewound
Resistance 10kOhm
ECCN Code EAR99
Termination Solder
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Tolerance ±5%
Size / Dimension Round - 0.752Dia x 1.000 H 19.10mmx25.40mm
Series 3600
Published 2003
Packaging Bulk

Physical

Terminal Shape HOOK
Mounting Type Panel Mount
Mount Panel
