E810K-SAY104-L
RoHS
/
Package /
Category Connectors, Interconnects / USB, DVI, HDMI Connectors
Description
HDMIReceptacle Connector 19 Position Surface Mount, Right Angle, Horizontal
PDF
/
Inventory: 6909
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Mating Cycles 10000
Number of Ports 1
Body/Shell Style JACK
Empty Shell NO
Number of Contacts 19
Contact Finish Gold
Shell Finish NICKEL
Shielding Shielded
Current Rating (Amps) 0.5A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 30VDC
Gender Receptacle
Connector Type HDMI
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Solder Retention
JESD-609 Code e4
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Shell/Shielding Material Copper Alloy
Insulation Material POLYAMIDE
Mounting Feature Flange, Horizontal
Mounting Type Surface Mount, Right Angle
Mount Horizontal, Surface Mount
