0743204007

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / USB, DVI, HDMI Connectors
Description Conn MicroCross RCP 24 POS 1.91mm Solder RA Thru-Hole 24 Terminal 1 Port Tray
PDF
/
Inventory: 8204
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Technical

Mating Cycles 100
Number of Ports 1
Max Voltage Rating (AC) 40V
Empty Shell NO
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 24
Contact Finish Gold
Insulation Color Natural
Current Rating 3A
Shielding Shielded
Orientation Right Angle
Pitch 1.91mm
Current Rating (Amps) 3A per Contact
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature POLARIZED
Voltage - Rated 40VAC
Gender Receptacle
Number of Rows 3
Connector Type DVI-D, Dual Link
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Board Guide
JESD-609 Code e3
Series MicroCross 74320
Packaging Tray
Operating Temperature -20°C~85°C

Physical

Shell/Shielding Material Steel
Housing Material Thermoplastic
Mounting Feature Flange, Horizontal
Mounting Type Panel Mount, Through Hole, Right Angle
Mount Horizontal, Through Hole
Contact Plating Gold, Tin
Contact Material COPPER ALLOY
